Description
Overview
Powerful Processor
DJI RC 2 is equipped with a powerful processor that features improved CPU and GPU performance. This ensures ultra-smooth app and system operation, delivering a seamless and intuitive control experience with every flight.
Video Transmission System
The next-gen DJI O4 video transmission technology supports 2.4GHz, 5.1GHz, [1] and 5.8GHz frequency bands, providing DJI RC 2 with enhanced anti-interference capabilities. When paired with drones that are compatible with O4, such as DJI Air 3, DJI RC 2 can achieve HD low-latency video transmission within a 20km max range. [2]
2T4R Antennas
DJI RC 2 integrates two built-in and two external antennas, supporting a 2T4R system. This doubles the number of both transmitter and receiver antennas compared to the previous generation DJI RC, enhancing signal strength and further improving transmission performance for smooth control and safer flight.
FHD Screen
DJI RC 2 features a 5.5-inch 1920×1080 built-in FHD screen capable of maintaining 700 nits of high brightness.
Storage Capacity
DJI RC 2 comes with 32 GB of built-in storage, [3] allowing for direct screen recording and caching. It also supports microSD card expansion for an additional storage option.
Light and Compact
Even with improved processing and video transmission performance, added antennas, and an active-cooling design, DJI RC 2 weighs just 420 grams. [4] This ensures a comfortable grip and effortless control, especially during extended use.
- In The Box: DJI RC 2 × 1
- Compatibility DJI Air 3, DJI Mini 4 Pro
Video Transmission
Operating Frequency
- 2.4000-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHzOperating frequency allowed varies according to country/region. Please refer to local laws and regulations for more information.
Antenna
- 4 antennas, 2T4R
Transmitter Power (EIRP)
- 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <23 dBm (CE)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
Wi-Fi
Protocol
- 802.11 a/b/g/n/ac/ax
Operating Frequency
- 2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHzOperating frequency allowed varies according to country/region. Please refer to local laws and regulations for more information.
Transmitter Power (EIRP)
- 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
Protocol
- Bluetooth 5.2
Operating Frequency
- 2.400-2.4835 GHz
Transmitter Power (EIRP)
- < 10 dBm
Screen
Resolution
- 1920×1080
Dimensions
- 5.5 inches
Frame Rate
- 60fps
Brightness
- 700 nits
Touch Control
- 10-point multi-touch
General Specs
Battery
- 18650 Li-ion, 22.32Wh (3.6V, 3100mAh×2)
Charging Type
- Supports up to 9V/3A fast charge.
Charging Time
- 1.5 hours (with 9V/3A charger)
Operating Time
- Max 3 hours
Tested in a 25° C (77° F) laboratory environment with DJI RC 2 connected to DJI Air 3 in normal flight status and recording 1080p/60fps video.
Operating Temperature
- -10° to 40° C (14° to 104° F)
Storage Temperature
- Within one month: -30° to 60° C (-22° to 140° F)
One to three months: -30° to 45° C (-22° to 113° F)
Three to six months: -30° to 35° C (-22° to 95° F)
More than six months: -30° to 25° C (-22° to 77° F)
Charging Temperature
- 5° to 40° C (41° to 104° F)
Supported Aircraft Models
- DJI Mini 4 Pro, DJI Air 3,DJI Air 3S
Will support more DJI aircraft in the future. Visit the official website for the latest information.
Global Navigation Satellite System
- GPS + BeiDou + Galileo
Dimensions
- Without control sticks: 168.4×132.5×46.2 mm (L×W×H)
With control sticks: 168.4×132.5×62.7 mm (L×W×H)
Weight
- Approx. 420 g
Model
- RC 2
Storage
Internal Storage Capacity
- 32GB + expandable storage (with microSD card)
The actual available storage space is approximately 21 GB.
Supported SD Cards
- UHS-I Speed Grade 3 rating microSD card or above.
Recommended microSD Cards
- SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
Lexar 256GB V30 A2 microSDXC
Samsung EVO 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Kingston 256GB V30 microSDXC
